Creator of Composite Diamond Coating®

Surface Technology, Inc. is the creator and technical leader of CDC - Composite Diamond Coating®, an exceptionally engineered coating of electroless nickel with fine diamond. The synergy of these materials makes CDC an exceptionally hard and wear resistant coating. CDC conforms to even the most complex geometries and is an excellent replacement for chrome plating. STI makes CDC available via coating services from its production facility as well as chemical products sold directly, through a network of distributors, and by agreement with licensees worldwide.

Contact STI for One-Plate® Electroless Nickel solutions, the simplest EN in the world. These One-Plate® systems use just one “Q” solution for both bath make-up and replenishment. This innovation by STI overcomes the many shortcomings of using three A, B, and C solutions. Available in low, medium, high phosphorous, and composite EN varieties. Naturally, all are RoHS compliant.”

NiSLIP™ 500 – Electroless Nickel - PTFE

NiSlip™ 500 Electroless Nickel – PTFE (EN-PTFE) coatings provide the following important benefits:


  • Low coefficient of friction / self-lubricity
  • Excellent release properties
  • Corrosion resistance
  • Able to be blackened by STI's Surf-Black process
  • Perfect conformity to complex geometries
  • Applicability to metals, alloys, ceramics, and plastics

These features reduce sliding wear and sticking problems, and have been utilized widely in the automotive, molding, textile, gear, aerospace, connectors, oil and gas, and assembly industries to name just a few. NiSlip™ 500 coatings have even received a positive review from the U.S. Food and Drug Administration (FDA) Department of Health and Human Services. Click here for details.



As a pioneer of EN-PTFE coatings since the 1970’s, STI is proud of the fact that our EN-PTFE solutions are the most widely used around the world.  We have achieved this distinction by continually investing in research to develop new versions of EN-PTFE with improved performance, economy and environmental benefits.  Today we have the best and broadest EN-PTFE product portfolio to meet the needs of any application including:
These systems offer the following important benefits:


    • Medium Phosphorous
    • High Phosphorous
    • High Speed
    • Long Life
    • Single Component One-Plate® Systems
    • RoHS, ELV, WEEE, and REACH Compliant
    • Made without PFOS, PFOA, and fluorinated surfactants
  • NiSlip™ 500 EN-PTFE is available from STI:
  •
    • As a coating from STI's production facility onto your parts.
    • In chemical products from STI for plating shops to use in their own facilities.
  •
  •


    These chemical components are formulated for maximum readability, convenience, and economy; and are backed up by STI's first hand practical knowledge of their operation. May be covered by one or more of the following United States Patens No. 4,997,686, 5,145,517, 5,300,330, 5,863,616, 6,306,466, 7,744,685, and 8,147,601, 8,598,260, 9,096,924, and 10,006,126, with others pending.

    NiSlip™ is a trademark of Surface Technology, Inc.
